SHENTUI/LANDNEO 35-10 Multifunctional Backhoe Loader, 3,300 kg Operating Weight, 1,000 kg Rated Load, 0.6 m³ Loader Bucket, 0.1 m³ Backhoe Bucket, 4WD

Product Highlights

The SHENTUI/LANDNEO 35-10 multifunctional backhoe loader combines front-end loading and rear digging functions in one machine. Its compact dimensions of 5,600 × 1,680 × 2,730 mm make it suitable for construction sites where equipment flexibility and operating space are important.

Key product features include:

• 3,300 kg total machine weight

• 1,000 kg rated loading capacity

• 0.6 m³ loader bucket capacity

• 0.1 m³ backhoe bucket capacity

• 4WD drive system

• Maximum travel speed of 18 km/h

• Hydraulic system pressure of 16 MPa

• Maximum gradeability of 30%

• Minimum turning radius of 3,000 mm

• 190° backhoe swing angle

• Articulated full hydraulic steering

• Front 2-speed and rear 2-speed transmission configuration

The 35-10 supports the current construction equipment focus on multifunctionality, compact jobsite operation, and improved equipment utilization. Its loader and backhoe configuration helps users handle multiple basic tasks with one machine.

Technical Specifications

Overall Dimensions and Performance

• Model: 35-10

• Overall dimensions: 5,600 × 1,680 × 2,730 mm

• Minimum ground clearance: 230 mm

• Total machine weight: 3,300 kg

• Hydraulic system pressure: 16 MPa

• Maximum travel speed: 18 km/h

• Maximum gradeability: 30%

• Minimum turning radius: 3,000 mm

Backhoe Specifications

• Maximum digging height: 3,700 mm

• Maximum digging radius: 3,398 mm

• Backhoe bucket capacity: 0.1 m³

• Backhoe swing angle: 190°

Loader Specifications

• Maximum unloading height: 2,650 mm

• Maximum unloading distance: 1,325 mm

• Loader bucket width: 1,600 mm

• Loader bucket capacity: 0.6 m³

• Maximum lifting height: 3,350 mm

• Rated loading capacity: 1,000 kg

• Three-cycle operating time: 5 seconds

Engine

• Engine model: Yunnei 490

• Optional engine information: New 490 option is listed in the source specification

• Rated speed: 2,200 r/min

• Cylinder and bore specification: 4-90, as listed in the source specification

Transmission and Steering

• Transmission type: Fixed-axis power-shift transmission

• Gear configuration: 2 forward and 2 reverse gears

• Hydraulic torque converter: ZL28F

• Steering system: Articulated full hydraulic steering

• Drive type: Four-wheel drive

Axles, Brakes, Tires, and Capacities

• Axle type: 50 loader short axle, as listed in the source specification

• Tire specification: 31 × 15.5-15

• Service brake: Oil-assisted drum brake

• Parking brake: Manual

• Fuel tank capacity: 20 L

• Hydraulic oil tank capacity: 20 L

• Wheelbase: 3,000 mm

Applications

The SHENTUI/LANDNEO 35-10 backhoe loader can be used for general construction and material-handling operations, including:

• Construction site loading and excavation

• Small-scale earthmoving

• Trenching and backfilling

• Material loading and transfer

• Farm and agricultural infrastructure work

• Road maintenance and site preparation

• Municipal construction support

• Utility and drainage projects

• Landscaping and general site work

The machine is most suitable for operations that require both front loader and rear backhoe functions. Actual performance depends on soil conditions, attachments, operator experience, and working environment.

Packaging and Delivery

Packaging and delivery arrangements should be confirmed with SHENTUI or LANDNEO according to the destination country, shipping method, and order quantity.

Before shipment, buyers should confirm:

• Final machine configuration

• Engine option

• Spare parts requirements

• Shipping dimensions and weight

• Port of loading and destination port

• Documentation and import requirements

• Warranty and after-sales service terms

The listed machine dimensions are 5,600 × 1,680 × 2,730 mm. Final shipping details may vary according to configuration and packaging method.

After-sales Service

Shentui Construction Machinery (Jining) Co., Ltd. has more than 10 years of experience in construction machinery manufacturing and provides OEM/ODM solutions. The company states that it serves customers in more than 32 countries.

SHENTUI/LANDNEO after-sales support can be discussed according to the order requirements and may include:

• Product configuration confirmation

• Operation and maintenance information

• Spare parts coordination

• Technical communication

• OEM/ODM project support

• International customer service

The supplier states that its factory uses automated production lines and quality-control procedures, with ISO-certified quality management information provided by the supplier. Specific warranty coverage, response time, spare parts availability, and service terms should be confirmed before purchase.

Frequently Asked Questions

1. What is the SHENTUI/LANDNEO 35-10?

The SHENTUI/LANDNEO 35-10 is a multifunctional backhoe loader with front loading and rear digging functions. It is designed for general construction, earthmoving, loading, and site preparation work.

2. What is the rated loading capacity of the 35-10 backhoe loader?

The rated loading capacity is 1,000 kg according to the provided technical specification.

3. What are the bucket capacities of this multifunctional loader?

The front loader bucket has a capacity of 0.6 m³, while the rear backhoe bucket has a capacity of 0.1 m³.

4. Is the SHENTUI/LANDNEO 35-10 equipped with four-wheel drive?

Yes. The technical specification identifies the drive system as four-wheel drive.

5. What are the overall dimensions of the 35-10 backhoe loader?

The overall dimensions are 5,600 mm in length, 1,680 mm in width, and 2,730 mm in height.

6. What engine is used in the 35-10 backhoe loader?

The listed engine model is Yunnei 490, with a rated speed of 2,200 r/min. A new 490 engine option is also listed in the provided specification. The final engine configuration should be confirmed when placing an order.
