LANDNEO WZ38-28 4WD Backhoe Loader | 8000kg Operating Weight | 1.5m³ Front Bucket & 0.3m³ Backhoe | Yuchai 75kW Turbo Engine | 4100mm Max Digging Depth | 30km/h Speed | SHENTUI

Product Highlights

In the global wave of "green infrastructure" and cost-efficiency, the LANDNEO WZ38-28 Backhoe Loader stands out for its compactness and versatility.

Powerful Performance & Efficient 4WD
Equipped with a Yuchai YCD4122T-115 turbocharged engine (75kW rated power), with optional Cummins or Euro 5 / EPA 4 engines to meet diverse global emission standards. Featuring a Yunyu front steering drive axle and a special 280 integral gearbox, the 4WD system ensures superior traction and gradeability on muddy and rough terrains. It reaches a maximum speed of 30km/h for efficient job site transitions.

Exceptional Digging & Loading Capacity
Standardly equipped with a 1.5m³ front bucket and a 0.3m³ backhoe bucket, with a loading lifting capacity of 2800KG. The maximum digging depth reaches 4100mm (optional extending arm extends it to 5000mm), and the backhoe swing angle is 190°. With a maximum pulling force of 39KN and a hydraulic system pressure of 22Mpa, the bucket discharge time is only 2.0 seconds, ensuring smooth operations and high earthmoving efficiency.

Smart & Comfortable Operating Experience
Embracing the "smart cabin" trend, the WZ38-28 features a luxury enclosed cab with an adjustable rotating seat, LCD display, hydraulic pilot control, heater, LED lights, and a large rearview mirror. The external air-over-oil caliper brake with self-regulation and self-balance ensures driving and parking safety, significantly reducing operator fatigue during long working hours.

Technical Specifications

• Overall Parameters: Operating Weight 8000KG; Transport Dimension 7600×2260×2890mm; Wheelbase 2250mm; Min. Ground Clearance 300mm.

• Loader Parameters: Bucket Capacity 1.5m³; Breakout Force 38KN; Dumping Height 2800mm; Dumping Distance 1062mm.

• Backhoe Parameters: Backhoe Capacity 0.3m³; Max. Digging Depth 4100mm (Optional 5000mm); Swing Angle 190°.

• Engine & Transmission: Standard Yuchai YCD4122T-115 (75KW); Torque Converter YJ280 Single-stage Three Elements; Fixed Shaft Power Transmission Gearbox (2 Gears Ahead, 2 Astern).

• Tires & Brakes: Front 14-17.5, Rear 19.5L-24 vacuum tires, 0.22Mpa pressure; Air Over Oil Caliper Service Brake + Manual Operation Power Terminating Brake.

Applications

As "global infrastructure expansion" accelerates, the WZ38-28 demonstrates exceptional adaptability:

• Municipal & Road Construction: With a top speed of 30km/h and a minimum turning radius of 6581mm, it navigates narrow city streets flexibly for trenching, cabling, and road maintenance.

• Agricultural & Orchard Operations: Combining digging and loading functions significantly reduces the cost of purchasing two separate machines, easily handling ditch cleaning, land leveling, and material handling.

• Mining & Building Sites: The 8000KG operating weight and powerful digging force are fully capable of handling medium-sized mining stripping and heavy-duty loading tasks on construction sites.

 Packaging and Delivery

To maximize logistical cost-efficiency, SHENTUI offers professional export packaging. A 40-foot High Cube container (1*40HC) can hold 2 units of this machine. Tires, backhoe arms, and buckets are disassembled, and process wheels are used for container loading to save space. With over 10 years of industry expertise and a mature logistics network in major Chinese ports, we ensure a 30-day fast lead time and safe delivery to clients in over 32 countries.

After-sales Service

The LANDNEO brand relies on the robust manufacturing and service system of Shentui Construction Machinery (Jining) Co., Ltd. As a leading manufacturer with over 10 years of expertise, our factory features advanced automated production lines and rigorous QC protocols to ensure ISO-certified quality. We provide reliable OEM/ODM solutions and robust after-sales support to global clients, including spare parts supply, technical guidance, and operational training to keep your equipment in optimal condition.

FAQ

Q1: What is the maximum digging depth of the LANDNEO WZ38-28 backhoe loader?
A1: The standard maximum digging depth is 4100mm. If you require deeper excavation, we offer an optional extending arm that extends the maximum digging depth to 5000mm.

Q2: Which engine is equipped in the WZ38-28, and can I choose a different one?
A2: The standard engine is a Yuchai YCD4122T-115 turbocharged engine with 75kW rated power. For different emission standards and power preferences, you can also choose optional engines including Yuchai 90KW, Cummins 74KW/75KW, and EURO5 Yuchai or EPA4 Cummins engines.

Q3: How many units can fit into a 40-foot High Cube container?
A3: We have optimized the packaging. A 40HQ container can hold 2 units of the WZ38-28. To achieve this, the tires, backhoe arm, and bucket are disassembled, and the machine is loaded using process wheels.

Q4: Is the WZ38-28 a 4WD machine, and what are the tire specifications?
A4: Yes, it features a robust 4WD system with a Yunyu steering drive axle. It uses vacuum tires: 14-17.5 for the front wheels and 19.5L-24 for the rear wheels, ensuring excellent traction and stability on various terrains.

Q5: Does the cab come with heating and air conditioning for extreme weather conditions?
A5: Yes. The WZ38-28 features a luxury enclosed cab equipped with heating, a fan, an adjustable rotating seat, and a liquid crystal display. These features are designed to provide a comfortable operating environment, reducing operator fatigue in both hot and cold climates.

Q6: What kind of after-sales support does SHENTUI provide for international buyers?
A6: With over 10 years of expertise and a presence in 32+ countries, Shentui provides comprehensive after-sales support. This includes reliable OEM/ODM solutions, fast spare parts supply, technical guidance, and operational training to ensure your project runs smoothly.
