08 Mini Excavator | 0.8 Ton Compact Digger with Yanmar Engine
Model: K08
Min. Order: 1 Unit
- Operating weight:
- 820 kg
- Bucket capacity:
- 0.03 m³
- Bucket width:
- 400 mm
- Working device form:
- Backhoe
Product Features & Applications
The 08 Mini Excavator is a 0.8-ton compact digger powered by a reliable Yanmar 192 engine. With an operating weight of 820kg, it features zero-tail swing design, easy operation, and built-in oil pipes for efficient performance. Certified by EPA and CE, this mini excavator offers a max digging depth of 1600mm, 2400mm digging height, and 17.5L hydraulic oil tank capacity, ideal for landscaping, construction, and small-scale earthmoving projects.
0.8 Ton Mini Excavator – Compact & Powerful for All Small Projects

Key Performance & Hydraulic System

Excellent Structural Design & Comfort

Wide Application & Certification

Why Choose Our K08 Mini Excavator?

- Stable Yanmar engine with low fuel consumption
- Zero tail swing for narrow-space operation
- EPA & CE certified for global market
- Compact size, easy transportation and maintenance
- High cost performance suitable for rental and personal use





Technical Specifications
- Operating weight
- 820 kg
- Bucket capacity
- 0.03 m³
- Bucket width
- 400 mm
- Working device form
- Backhoe
- Fuel tank capacity
- 7.5 L
- Engine Model
- Yanmar 192
- Chassis width
- 930 mm
- Max. travel speed
- 2.5 km/h
- Max. digging radius on ground
- 2950 mm
- Swing speed
- 9.5 rpm
- Max. digging radius
- 2950 mm
- Max. Grade ability
- 30°
- Max. digging depth
- 1600 mm
- Bucket digging force
- 12 KN
- Max. digging height
- 2400 mm
- Bucket arm digging force
- 7.6 KN
- Max. dumping height
- 1600 mm
- Maximum tractive force
- 10 KN
- Maximum vertical digging depth
- 1500 mm
- Track Material
- rubber
- Minimum turning radius
- 1400 mm
- Track Model
- 1807237
- Maximum Lift Of Dozer blade
- 140 mm
- Crawler tension device
- Mechanical tensioning
- Maximum depth Of Dozer blade
- 240 mm
- Ground pressure
- 21 kPa
- Pump type
- Gear pump
- Pressure
- 15 MPa
- Displacement
- 10 L/min
- Rotary hydraulic motor
- Cycloidal motor
- Walking hydraulic motor
- Cycloidal motor
- Hydraulic manifold valve
- Mechanical valve
- Hydraulic oil tank capacity
- 17.5 L
- Wheel base
- 970 mm
- Track length
- 1200 mm
- Upper chassis ground clearance
- 350 mm
- Counter weight turning radius
- 760 mm
- Transportation length
- 2800 mm
- Total height
- 2150 mm
Trade Specifications
- Reference Price
- USD $1000.00 - $2000.00
- Minimum Order Quantity
- 1 Unit
Jining Jiahe Intelligent Heavy Industry Machinery Co., Ltd.
Jining Jiahe Intelligent Heavy Industry Machinery Co., Ltd. is a high-tech enterprise specializing in the R&D, production and sales of small and medium-sized machinery and equipment. Located in Jining City, Shandong Province, the company relies on a mature manufacturing system and innovative technologies to provide customers with efficient, intelligent and durable construction machinery and garden equipment. The company's main products include lawn mowers, skid steer loaders, excavators and other small and medium-sized machinery, which are widely used in agriculture, landscaping, construction, municipal engineering and other fields. Adhering to the core philosophy of "Quality-oriented, Innovation-driven", Jiahe Intelligent Heavy Industry has won the trust of customers at home and abroad through strict quality control and attentive after-sales service, with products exported to many countries and regions around the world. 2. Company Advantages Advanced Technology: Introducing advanced production technology and intelligent technology to ensure high efficiency, energy saving and easy operation of equipment. Quality Assurance: Strictly following international quality standards with full-process quality inspection from raw materials to finished products, leading the industry in durability. Diverse Products: Covering multi-scenario demands such as mowing, loading and excavating to meet one-stop procurement for different customers. Comprehensive Service: Providing pre-sales consultation, after-sales maintenance and technical training, responding to customer needs 24 hours a day. High Cost Performance: Offering cost-effective solutions for customers through large-scale production and supply chain advantages. 3. Company Slogans Main Slogan:"Jiahe Intelligent Manufacturing, Efficient and Reliable – Making Engineering Easier!" Alternative Slogans:"Intelligent Machinery, Efficient Operation – Jiahe Creates the Future with You!""Professional Quality, Meticulous Craftsmanship – Jiahe Heavy Industry, Empowering Every Endeavor!" 4. Product Application Introduction Lawn Mower Application: Suitable for weed trimming and vegetation maintenance in lawns, orchards, parks and other areas, improving greening efficiency.Features: Light and flexible, low noise, durable blades, adaptable to various terrains. Skid Steer Loader Application: Widely used in construction, farm handling, snow removal and other scenarios, with quick-change attachments (such as buckets, forklift arms).Features: Compact body, flexible steering, strong power, ideal for operations in narrow spaces. Mini Excavator Application: Used for small earthwork projects such as municipal engineering, farmland water conservancy, and pipeline laying.Features: Simple operation, low fuel consumption, strong stability, balancing power and precision.
- Location
- Room 1201, 12th Floor, Shengyuan Building, Guanyinge Subdistrict, Rencheng District, Jining City, Shandong Province
