Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home

Electric linear actuator converts motor rotary motion into linear reciprocating motion to realize push, pull, lift, tilt and adjustment. It is clean, precise, energy-saving and quiet, widely used in industrial automation, medical, home, agriculture, automotive and other fields.
$1.00 - 500.00
Dezhou Darui Machinery Equipment Co., Ltd.

Dezhou Darui Machinery Equipment Co., Ltd.

View Supplier
Registration Date March 2, 2017
Number of Employees 20
Factory Area 4,580 m²
Annual Sales 15 Million RMB
Main Products Screw Jacks, Ball Screw Jacks, Electric Linear Actuators
Target Markets Global
Details
Specifications
Product Overview
Electric linear actuator is an electromechanical device that converts motor rotary motion into linear reciprocating motion. Composed of motor, gearbox, screw, nut, push rod and limit switches, it realizes push, pull, lift, tilt and angle adjustment. It replaces traditional pneumatic and hydraulic cylinders with cleaner, more precise, energy-saving and easier maintenance.
2. Working Principle
Motor power on → Gear reduction & torque increase → Drive screw rotation → Nut linear movement → Push rod extension. Trapezoidal screw provides power-off self-locking; can be equipped with encoder for high-precision positioning.
3. Product Types
  • Trapezoidal screw type: strong self-locking, low cost, general purpose
  • Ball screw type: high efficiency, high precision, for high-frequency applications
  • Pen/tubular type: compact, quiet, for medical, home and small equipment
4. Key Advantages
  • Clean & eco-friendly, no oil, no gas, no leakage
  • High precision positioning, support multi-unit synchronization
  • Energy saving & low noise (<50dB)
  • Flexible installation, multi-direction mounting, no pipeline required
  • Safe & reliable, self-locking when power off, overload protection
5. Application Scenarios
Industrial automation, medical equipment, smart home, agricultural machinery, solar tracking, automotive modification, special vehicles, sanitation equipment, lifting platforms, etc.
Product Name
Electric Linear Actuator
Thrust Force
50N–20000N (0.5kg–2ton)
Stroke
50mm–1500mm (Customizable)
Speed
5mm/s–160mm/s
Voltage
DC12V/24V/36V/48V; AC220V/380V
Protection Grade
IP54 / IP65 / IP66 / IP67
Positioning Accuracy
±0.1mm (Standard)
Screw Type
Trapezoidal Screw / Ball Screw
Duty Cycle
10%–30% (Trapezoidal); 60%–100% (Ball)
Operating Temperature
-20℃~+60℃
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home
  • Electric Linear Actuator, DC Reciprocating Push Pull Lift Motor for Industrial, Medical, Home

Description

Product Overview
Electric linear actuator is an electromechanical device that converts motor rotary motion into linear reciprocating motion. Composed of motor, gearbox, screw, nut, push rod and limit switches, it realizes push, pull, lift, tilt and angle adjustment. It replaces traditional pneumatic and hydraulic cylinders with cleaner, more precise, energy-saving and easier maintenance.
2. Working Principle
Motor power on → Gear reduction & torque increase → Drive screw rotation → Nut linear movement → Push rod extension. Trapezoidal screw provides power-off self-locking; can be equipped with encoder for high-precision positioning.
3. Product Types
  • Trapezoidal screw type: strong self-locking, low cost, general purpose
  • Ball screw type: high efficiency, high precision, for high-frequency applications
  • Pen/tubular type: compact, quiet, for medical, home and small equipment
4. Key Advantages
  • Clean & eco-friendly, no oil, no gas, no leakage
  • High precision positioning, support multi-unit synchronization
  • Energy saving & low noise (<50dB)
  • Flexible installation, multi-direction mounting, no pipeline required
  • Safe & reliable, self-locking when power off, overload protection
5. Application Scenarios
Industrial automation, medical equipment, smart home, agricultural machinery, solar tracking, automotive modification, special vehicles, sanitation equipment, lifting platforms, etc.
