Air Suspension Series | 13t/18t Commercial Vehicle Trailer Air Suspension System for Heavy-duty Refrigerated & Overweight Cargo Trucks

Name: Air Suspension Series | 13t/18t Commercial Vehicle Trailer Air Suspension System for Heavy-duty Refrigerated & Overweight Cargo Trucks
Brand: GLOBALMACHEX
Availability: InStock
Rating: 5 (1 reviews)

This air suspension series is designed for commercial vehicles and trailers, with 13-ton and 18-ton models. It adopts airbag shock absorption structure, compatible with Φ150 axle tube, 420-518mm installation height, and 980-828mm axle. It improves ride comfort, extends the service life of cargo and chassis components, and is widely used in refrigerated trucks, box trucks and overweight cargo trailers.

$1200.00

Send Message Contact Supplier

Shandong Shuibo Electromechanical Equipment Co., Ltd.

View Supplier

Registration Date March 26, 2010

Number of Employees 30

Factory Area 2,000 m²

Annual Sales 50 Million RMB

Main Products Wheel Hub, Suspension, Air Reservoir, Leaf Spring, Air Bag, Flux, Welding Wire, Brake Pad

Target Markets Central Asia, Africa, Southeast Asia

Details

Specifications

This air suspension series is a high-performance suspension system tailored for commercial vehicles and trailers. It adopts advanced airbag shock absorption structure to effectively absorb road shocks, significantly improve ride comfort, reduce cargo vibration damage, and extend the service life of chassis components. It is an ideal upgrade solution for refrigerated trucks, box trucks, overweight cargo trailers and other models.

The series includes two core models to meet different load scenarios:

SPK1701Z-08: Rated load 13 tons, suitable for light-duty trailers and conventional box trucks, balancing economy and comfort.
SPK1700Z-08: Rated load 18 tons, specially designed for heavy-duty conditions with strong load-bearing capacity, suitable for overweight cargo transportation and engineering trailers.

Structure and Adaptability

Installation and Compatibility Parameters
The installation height is adjustable from 420-518mm, compatible with Φ150mm axle tube, 1848mm axle track, and 980-828mm axle specifications. It supports multiple tire sizes to meet the modification needs of different models.
Shock Absorption and Load-bearing Performance
The airbag specification is Φ345 with a total stroke of 498mm, which can effectively filter road bumps and greatly reduce the risk of cargo damage. At the same time, the thickened steel plate structure ensures load stability and adapts to heavy-duty transportation conditions.
Application Scenarios
Widely used in refrigerated trucks, box trucks, overweight cargo trailers, engineering trailers and other models. It can provide stable and reliable suspension support for both urban distribution and long-distance heavy-duty transportation.

Model

SPK1701Z-08, SPK1700Z-08

Rated Load

13 ton, 18 ton

Installation Height

420-518mm

Axle Tube Diameter

Φ150mm

Axle Track

1848mm

Compatible Axle

980-828mm

Bracket Height

245-435mm

Airbag Center Distance

68mm

Airbag Specification

Φ345

Airbag Total Stroke

498mm

Installation Slope

8.5°-20°

Compatible Tire Size

11.00R20、12R22.5、22.5×8.25

Application

Light trailer, Heavy trailer, Refrigerated truck, Oversized cargo vehicle

Description

The series includes two core models to meet different load scenarios:

SPK1701Z-08: Rated load 13 tons, suitable for light-duty trailers and conventional box trucks, balancing economy and comfort.
SPK1700Z-08: Rated load 18 tons, specially designed for heavy-duty conditions with strong load-bearing capacity, suitable for overweight cargo transportation and engineering trailers.

Structure and Adaptability

Installation and Compatibility Parameters
The installation height is adjustable from 420-518mm, compatible with Φ150mm axle tube, 1848mm axle track, and 980-828mm axle specifications. It supports multiple tire sizes to meet the modification needs of different models.
Shock Absorption and Load-bearing Performance
The airbag specification is Φ345 with a total stroke of 498mm, which can effectively filter road bumps and greatly reduce the risk of cargo damage. At the same time, the thickened steel plate structure ensures load stability and adapts to heavy-duty transportation conditions.
Application Scenarios
Widely used in refrigerated trucks, box trucks, overweight cargo trailers, engineering trailers and other models. It can provide stable and reliable suspension support for both urban distribution and long-distance heavy-duty transportation.
